BW-TIG 200 AC/DC

200AMP Inverter Tig/Arc AC/DC Pulse Welder

Ideal for TIG welding aluminium and all steels from 0.3 - 10mm. With all the controls plus a digital read-out, this inverter is exceptionally smooth and easy to operate. It has all the features of a professional machine housed in a compact case.

  • Powerful - 160A TIG. 140A MMA. 30A plasma output current -Welds up to 12mm - Cuts up to 8mm
  • Portable - At 18kg this machine is portable and robust
  • Reliable - Cutting edge IGBT Inverter Technology
  • Product Description

  • Products specifications

The BW-TIG 200 AC/DC offers a solid 200A MMA (ARC weldng ability), is designed specifically for industry and incorporates the latest in TIG welding technology. Exclusive HF Inverter technology means you have more advantages, smaller footprint, lighter weight and a much higher power efficiency than other TIG welders available today.

  • Single phase, 240V input power.
  • 20 - 200A TIG and ARC welding power
  • HF Start TIG welding with 2T/4T TIG function.
  • ARC force adjustment.
  • 60% at 200A duty cycle.
  • Adjustable pulse frequency and pulse current.
  • Post and pre-flow gas adjustment.
  • 15A Plug - Ideal for workshop power supplies
  • Optional foot control available
  • 18 Month Trade Warranty
Attribute nameAttribute value
Input Power Voltage Freq. (V):220+/-15%50/60Hz Single phase R
Max Weld Thickness (mm):10
Rated Input Power Capacity (KVA):3.9
Rod Diameter (mm):1.6 - 4
No Load Voltage (V):56
Postflow Time (Seconds)2- 10
Output Current Range (A)20 - 200
Insulation ClassF
Rated Output Voltage (V)17.4
Weight (kg)20
Duty Cycle %60% @200A 100% @140A
Overall Dimensions (mm):493 x 330 x 320

Suitable For

DIY or Small Projects DIY or Small Projects
